Urinal systems
Urinal support frame Blue powder coated frame Adjustable feet (20 cm) Pre-assembled wall fixation kit 380 mm wide Incl. fixation materials, elbow 50 mm Max 280 offset for urinal fixation
Urinal support frame Blue powder coated frame Adjustable feet (20 cm) Pre-assembled wall fixation kit 380 mm wide Incl. fixation materials, elbow 50 mm Max 285 offset for urinal fixation Pre-assembled in-wall mounted box, with ball valve, pressure flush mechanism and pipe up to the water supply Waterconnection 1/2” Styropor masonry aid Flushing pressure: 1,2-4,0 bar Flush volume: consistant 3 ± 0,5 l
The NIL construction kit with flushing valve is used in the WISA XS urinal (art. no. 8050452757) and consists of the following parts:built-in cabinet with coverflushing valve< /li>ball valvesealing ringconnecting piecebolt M4 x 8 mmwasher recess blockCylinder screw M5 x 40 mmball valve ring of pressure flush valveinstructions
Urinal support frame Blue powder coated frame Adjustable feet (20 cm) Pre-assembled wall fixation kit 380 mm wide Incl. fixation materials, elbow 50 mm Max 280 offset for urinal fixation Pre-assembled in-wall mounted box, with ball valve, pressure flush mechanism and pipe up to the water supply Waterconnection G 1/2 Styropor masonry aid Flushing pressure: 1,2-4,0 bar Flush volume: consistant 3 ± 0,5 l
